Water Testing

Platinum facades offer both Hose bar testing and spray bar testing: Site Hose Testing for Curtain Walls & Sloped Glazing Systems in accordance with the CWCT Standards for Systemised Building Envelopes: 2006 and AAMA 501.2-15

Hose testing

Hose testing is intended for the testing of permanently sealed joints of the installed cladding system to ensure that the fabrication and installation have not in any way reduced the performance of the system, and to check the performance of interfaces with adjacent systems that did not form part of the laboratory test.


The high-pressure water spray should not dislodge gaskets or wet applied sealants unless they have been poorly installed or have not been allowed to cure. Water will be forced through small gaps in these types of seals and will find its way through unsealed joints between framing components. Hose testing is not suitable, in its unmodified form, for use on open joints even if these are baffled as the flow of water from the nozzle will overwhelm most open joints or joints that are intended to open. If the hose test is used on open or opening joints, then the normal procedure is to reduce the nozzle pressure. However, the spray bar test is more applicable for this type of joint.

Spray Bar testing

Spray Bar Testing covered by the Standard BS EN 13051: 2001 and CWCT 2006. This method of testing is suitable for open – jointed systems (eg. rainscreen cladding, unsealed patent glazing, opening lights/doors and smoke vents. The flow rate and pressure is controlled to give a continuous film of water to the face of the cladding system, water is therefore not forced into the joints and reflects an accurate weather test of the system. Our spray bar rig can be lowered up to 30 metres from the above floor slabs or roof areas testing the cladding or sloped glazing systems. The standard spray bar spans 4.8 metres with 12 nozzles but can be modified to suit the requirements of the job profile.
